Brand: MAHR
SKU: 31938350

Brand: MAHR

Art.-no. 31938350

Manufacturer article no. 4455008

EAN 4059192017897

All versions

Similar products

Individual prices for customers after login

Art.-no. 31938350

Quantity

Price per

Piece

You need more information or have not found your desired product?

Login/Register
Call customer service: +33 (0)1 69 19 43 90

Application

For precise testing of cylindrical parts directly on the machine tool.

Execution

Carbide measuring faces
Movable anvil spring-mounted on bottom
Consistent, repeatable measuring force
Forged steel bracket
Both measuring probes made from stainless, hardened steel
Adjustable centring stop

Notes

Other sizes up to 500 mm available on request

Delivery

In wooden box, display unit not included

Product information

HAHN+KOLB Catalogue

Certificates/ Documents


Brand	MAHR
EAN	4059192017897
Manufacturer Part Number	4455008
Min./max. length measuring range	350-400 mm
Shank diameter	8 mm
Measuring surface diameter	20 mm
Measurement force	15 N
Spindle clamping	Yes
Harmonized System Code	90178090
Gross Weight	8.100 kg
